ADS774JU
Or copy the link below:
- Mfr.Part #
- ADS774JU
- Manufacturer
- Texas Instruments
- Package / Case
- 28-SOIC (0.295, 7.50mm Width)
- Datasheet
- Download
- Description
- IC ADC 12BIT SAR 28SOIC
- Stock
- 8
- In Stock ：
- 8
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Texas Instruments
- Product Category :
- Analog to Digital Converters (ADC)
- Radiation Hardening :
- No
- Integral Nonlinearity (INL) :
- 1 LSB
- Pbfree Code :
- yes
- Contact Plating :
- Gold
- Lead Free :
- Lead Free
- Width :
- 7.5mm
- Number of Bits :
- 12
- Height :
- 2.65mm
- Factory Lead Time :
- 6 Weeks
- Peak Reflow Temperature (Cel) :
- 260
- Power Dissipation :
- 120mW
- Converter Type :
- ADC, SUCCESSIVE APPROXIMATION
- Ratio - S/H:ADC :
- 1:1
- Spurious-free dynamic range (SFDR) :
- 78 dB
- Number of Channels :
- 1
- Package / Case :
- 28-SOIC (0.295, 7.50mm Width)
- Base Part Number :
- ADS774
- Number of Analog In Channels :
- 1
- Pin Count :
- 28
- JESD-609 Code :
- e4
- Architecture :
- SAR
- Output Bit Code :
- BINARY, OFFSET BINARY
- Signal to Noise Ratio (SNR) :
- 72 dB
- Data Interface :
- Parallel
- Negative Supply Voltage-Nom :
- -15V
- Number of Functions :
- 1
- Supply Current-Max :
- 24mA
- RoHS Status :
- ROHS3 Compliant
- Max Power Dissipation :
- 120mW
- Polarity :
- Bipolar, Unipolar
- REACH SVHC :
- No SVHC
- Operating Temperature :
- -40°C~85°C
- Thickness :
- 2.35mm
- Reference Type :
- External, Internal
- Min Supply Voltage (DC) :
- 4.5V
- Input Type :
- Single Ended
- Number of Terminations :
- 28
- Max Supply Voltage (DC) :
- 5.4V
- Number of Pins :
- 28
- Linearity Error-Max (EL) :
- 0.0244%
- Sampling Rate :
- 125 ksps
- Operating Supply Voltage :
- 5V
- Configuration :
- S/H-ADC
- Moisture Sensitivity Level (MSL) :
- 3 (168 Hours)
- Lifecycle Status :
- ACTIVE (Last Updated: 6 days ago)
- Min Supply Voltage :
- 4.5V
- Supply Voltage :
- 5V
- Mounting Type :
- Surface Mount
- Supply Type :
- Analog, Digital, Dual, Single
- Terminal Form :
- Gull wing
- Length :
- 17.9mm
- Power Consumption :
- 75mW
- Sampling Rate (Per Second) :
- 125k
- Packaging :
- Tube
- Resolution :
- 1.5 B
- ECCN Code :
- EAR99
- Conversion Rate :
- 125 ksps
- Sample and Hold / Track and Hold :
- SAMPLE
- Max Supply Voltage :
- 5.5V
- Voltage - Supply, Analog :
- 5V -16.5V~5.5
- Voltage - Supply, Digital :
- 5V
- Surface Mount :
- yes
- Datasheets
- ADS774JU
Analog to Digital Converters (ADC) Texas Instruments ADS774JU Overview
The Texas Instruments ADS774JU is a high-performance 12-bit successive approximation register (SAR) analog-to-digital converter (ADC) that combines robust design with high precision and efficiency. Designed to address the demanding needs of sophisticated electronic systems, this ADC offers an exceptional balance of speed and resolution, making it ideal for a variety of demanding applications. The Analog to Digital Converters (ADC) Texas Instruments ADS774JU is encapsulated in a 28SOIC package, providing a compact solution while ensuring easy integration into existing technology platforms.
ADS774JU Features
The ADS774JU boasts several key features that make it stand out. It offers a 12-bit resolution, ensuring precise digital output from analog inputs. The fast conversion rate enhances system responsiveness. Additionally, the device's low power consumption makes it suitable for power-sensitive applications. Its wide input range and ease of interface with various microprocessors and DSPs further enhance its versatility, making it an excellent choice for both new designs and upgrades to existing systems.
ADS774JU Applications
- Medical Imaging Systems: Utilized in devices such as MRI and ultrasound scanners, where precision and speed are crucial for producing detailed images.
- Industrial Automation: Integral in controlling and monitoring systems where accurate analog to digital conversion is essential for operational efficiency.
- Data Acquisition Systems: Serves as a core component in systems requiring high-speed and accurate data capture from various sensors.
- Communication Systems: Helps in precise signal processing tasks critical in telecommunications equipment.
