BAV70

Manufacturer :

SMC Diode Solutions

Product Category :

Diodes - Rectifiers - Arrays

Voltage - Forward (Vf) (Max) @ If :

1.25V @ 150mA

Pin Count :

3

Diode Type :

Standard

Package / Case :

TO-236-3, SC-59, SOT-23-3

Number of Elements :

2

Mounting Type :

Surface Mount

Additional Feature :

ULTRA FAST

RoHS Status :

ROHS3 Compliant

Surface Mount :

yes

Packaging :

Tape and Reel (TR)

Terminal Finish :

MATTE TIN

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Terminal Form :

Gull wing

Rep Pk Reverse Voltage-Max :

70V

Diode Element Material :

SILICON

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Current - Average Rectified (Io) :

200mA

Qualification Status :

COMMERCIAL

Current - Reverse Leakage @ Vr :

5μA @ 70V

Number of Terminations :

3

JESD-30 Code :

R-PDSO-G3

Speed :

Small Signal =< 200mA (Io), Any Speed

Terminal Position :

Dual

Reverse Recovery Time :

6ns

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Voltage - DC Reverse (Vr) (Max) :

70V

Reach Compliance Code :

Unknown

Diode Configuration :

1 Pair Common Cathode

Output Current-Max :

0.2A

Pbfree Code :

yes

JESD-609 Code :

e3

Power Dissipation-Max :

0.35W

Operating Temperature - Junction :

150°C Max
