LSM6DS3TR
Or copy the link below:
- Mfr.Part #
- LSM6DS3TR
- Manufacturer
- STMicroelectronics
- Package / Case
- 14-VFLGA Module
- Datasheet
- Download
- Description
- IMU ACCEL/GYRO I2C/SPI 14VFLGA
- Stock
- 7,496
- In Stock ：
- 7,496
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- STMicroelectronics
- Product Category :
- Motion Sensors - IMUs (Inertial Measurement Units)
- Contact Plating :
- Gold
- Series :
- iNEMO
- HTS Code :
- 8542.39.00.01
- Min Supply Voltage :
- 1.62V
- Length :
- 3mm
- JESD-609 Code :
- e4
- Package / Case :
- 14-VFLGA Module
- Terminal Pitch :
- 0.5mm
- Factory Lead Time :
- 16 Weeks
- Height :
- 860μm
- Mounting Type :
- Surface Mount
- Mount :
- Surface Mount
- Output Type :
- I2C, SPI
- Lead Free :
- Lead Free
- Number of Pins :
- 14
- Number of Terminations :
- 14
- Base Part Number :
- LSM6D
- Number of Functions :
- 1
- Moisture Sensitivity Level (MSL) :
- 3 (168 Hours)
- RoHS Status :
- ROHS3 Compliant
- Max Supply Voltage :
- 3.6V
- Packaging :
- Cut Tape (CT)
- ECCN Code :
- EAR99
- Analog IC - Other Type :
- ANALOG CIRCUIT
- Terminal Position :
- BOTTOM
- Operating Temperature :
- -40°C~85°C TA
- Lifecycle Status :
- ACTIVE (Last Updated: 7 months ago)
- Width :
- 2.5mm
- REACH SVHC :
- No SVHC
- Supply Voltage :
- 1.8V
- Sensor Type :
- Accelerometer, Gyroscope, Temperature, 6 Axis
- Terminal Form :
- BUTT
- Datasheets
- LSM6DS3TR
LSM6DS3TR datasheet pdf and Motion Sensors - IMUs (Inertial Measurement Units) product details from STMicroelectronics stock available at
LSM6DS3TR Description
The LSM6DS3 is a system-in-package featuring a 3D digital accelerometer and a 3D digital gyroscope
performing at 1.25 mA (up to 1.6 kHz ODR) in highperformance mode and enabling always-on low-power features for an optimal motion experience for the consumer. The LSM6DS3 supports main OS requirements, offering real, virtual and batch sensors with 8 kbyte for dynamic data batching.
LSM6DS3TR Features
· Power consumption: 0.9 mA in combo normal mode
and 1.25 mA in combo high-performance mode up to
1.6 kHz.
· “Always-on” experience with low power
consumption for both accelerometer and gyroscope
· Smart FIFO up to 8 kbyte based on features set
· Compliant with Android K and L
· Hard, soft ironing for external magnetic sensor
corrections
· ±2/±4/±8/±16 g full scale
· ±125/±250/±500/±1000/±2000 dps full scale
· Analog supply voltage: 1.71 V to 3.6 V
· Independent IOs supply (1.62 V)
· Compact footprint, 2.5 mm x 3 mm x 0.83 mm
· SPI/I2C serial interface with main processor data
synchronization feature
· Embedded temperature sensor
· ECOPACK®, RoHS and “Green” compliant
LSM6DS3TR Applications
· Pedometer, step detector and step counter
· Significant motion and tilt functions
· Indoor navigation
· Tap and double-tap detection
· IoT and connected devices
· Intelligent power saving for handheld devices
· Vibration monitoring and compensation
· Free-fall detection
· 6D orientation detection
