NLSV4T244MUTAG

Manufacturer :

onsemi

Product Category :

Translators, Level Shifters

Feature :

Over Voltage Protection, Power-Off Protection

Supply Voltage :

1.2V

Turn On Delay Time :

5.3 ns

Height :

550μm

Number of Outputs :

1

Radiation Hardening :

No

Peak Reflow Temperature (Cel) :

260

Published :

2007

Operating Temperature :

-40°C~85°C TA

Contact Plating :

Gold

Number of Terminations :

12

Max Supply Voltage :

4.5V

Pbfree Code :

yes

Low Level Output Current :

24mA

REACH SVHC :

No SVHC

Voltage - VCCB :

0.9V~4.5V

Translator Type :

Voltage Level

Number of Ports :

2

Output Characteristics :

3-STATE

Voltage - VCCA :

0.9V~4.5V

Number of Pins :

12

Propagation Delay :

1.6 ns

Ambient Temperature Range High :

105°C

Base Part Number :

NLSV4T244

Mounting Type :

Surface Mount

Package / Case :

12-UFQFN

Min Supply Voltage :

900mV

Channel Type :

Unidirectional

Number of Functions :

1

Time@Peak Reflow Temperature-Max (s) :

40

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Circuits :

1

Logic Function :

Translator

Packaging :

Tape and Reel (TR)

Lifecycle Status :

ACTIVE (Last Updated: 1 day ago)

Logic IC Type :

BUS DRIVER

Mount :

Surface Mount

Pin Count :

12

Terminal Position :

QUAD

Number of Bits :

4

Lead Free :

Lead Free

Nominal Supply Current :

4μA

Factory Lead Time :

10 Weeks

JESD-609 Code :

e4

Halogen Free :

Halogen Free

Output Polarity :

TRUE

Family :

4T

Number of Channels :

4

RoHS Status :

ROHS3 Compliant

Length :

2mm

High Level Output Current :

-24mA

Quiescent Current :

4μA

Output Type :

Tri-State, Non-Inverted
