9812R5KL2.0
Or copy the link below:
- Mfr.Part #
- 9812R5KL2.0
- Manufacturer
- Sensata Technologies – BEI Sensors
- Package / Case
- Box with Connector
- Datasheet
- Download
- Description
- SENSOR ROTARY CONNECTOR
- Stock
- 145
- In Stock ：
- 145
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Sensata Technologies – BEI Sensors
- Product Category :
- Position Sensors - Angle, Linear Position Measuring
- Sensing Method :
- Resistive
- Linearity :
- ±2%
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Series :
- 9800
- Tolerance :
- 20%
- Factory Lead Time :
- 8 Weeks
- Package / Case :
- Box with Connector
- Number of Pins :
- 3
- Min Operating Temperature :
- -40°C
- Packaging :
- Box
- For Measuring :
- Rotary Position
- Mounting Type :
- Chassis Mount
- Max Operating Temperature :
- 135°C
- RoHS Status :
- Non-RoHS Compliant
- Termination :
- Connector
- Length :
- 19.9898mm
- Termination Style :
- Connector
- Power Rating :
- 150mW
- Actuator Type :
- Hole for Shaft
- Number of Contacts :
- 50
- Output :
- Resistive
- Resistance :
- 5kOhms
- Datasheets
- 9812R5KL2.0
9800 Series For Measuring Rotary Position Connector Hole for Shaft Resistive ±2% Resistive Box with Connector
9812R5KL2.0 Overview
In order to protect the linear position measuring sensors from damage, they are packaged in Box with Connector packages. The Box package houses this electronic component. Angle position sensors should be operated at a minimum temperature of -40°C to ensure optimal operation. Sensors measuring angle position cannot operate above 135°C. A linear position measuring sensor can oppose the passage of current through 5kOhms. It has pins 3 for measuring linear position.
9812R5KL2.0 Features
9800 Series
Package / Case: Box with Connector
Mounting Type: Chassis Mount
3 Pins
9812R5KL2.0 Applications
There are a lot of Sensata-BEI Sensors
9812R5KL2.0 Angle & Linear Position Measuring Sensors applications.
- Dishwasher control systems
- Automotive temperature range
- Robotic joint position detection
- Industrial motor position control
- Medical robots and fitness equipment
- Absolute Rotary Position Sensor
- Steering Wheel Position Sensor
- Pedal Position Sensor
- Motor-shaft Position Sensor
- Throttle Position Sensor
