MPXHZ6400AC6T1
Or copy the link below:
- Mfr.Part #
- MPXHZ6400AC6T1
- Manufacturer
- NXP Semiconductors
- Package / Case
- 8-SOIC (0.335, 8.50mm Width), Top Port
- Datasheet
- Download
- Description
- SENSOR PRESSURE ABS AXIAL 8-SSOP
- Stock
- 9,504
- In Stock ：
- 9,504
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- NXP Semiconductors
- Product Category :
- Pressure Sensors, Transducers
- Termination Style :
- Gull wing
- Offset-Nom :
- 0.20V
- Voltage - Supply :
- 4.64V~5.36V
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- HTS Code :
- 8542.31.00.01
- Port Size :
- Male - 0.13 3.3mm Tube
- Output Type :
- Analog Voltage
- Surface Mount :
- yes
- Body Breadth :
- 8.5 mm
- Accuracy :
- ±1.5%
- Body Height :
- 9.65mm
- Package / Case :
- 8-SOIC (0.335, 8.50mm Width), Top Port
- Body Length or Diameter :
- 8.5mm
- Pressure Range-Max :
- 58 Psi
- Mounting Feature :
- Surface Mount
- Pressure Type :
- Absolute
- Sensitivity (mV/V) :
- 12.1 mV/V
- Operating Temperature :
- -40°C~125°C
- Port Style :
- Barbless
- Applications :
- Board Mount
- ECCN Code :
- EAR99
- Published :
- 2003
- Series :
- MPXHZ6400A
- Packaging :
- Tape and Reel (TR)
- Sensors/Transducers Type :
- PRESSURE SENSOR,PEIZORESISTIVE
- Maximum Pressure :
- 232.06PSI (1600kPa)
- Housing :
- Plastic
- RoHS Status :
- ROHS3 Compliant
- Feature :
- Temperature Compensated
- Factory Lead Time :
- 12 Weeks
- Response Time :
- 1000 μs
- Operating Pressure :
- 2.9PSI ~ 58.02PSI (20kPa ~ 400kPa)
- Output :
- 0.2 V ~ 4.8 V
- Datasheets
- MPXHZ6400AC6T1
MPXHZ6400A Series Absolute Pressure Sensor Analog Voltage -40°C~125°C 2.9PSI ~ 58.02PSI (20kPa ~ 400kPa) Barbless ±1.5% 0.2 V ~ 4.8 V 4.64V~5.36V Temperature Compensated
MPXHZ6400AC6T1 Overview
For convenience, this transducer is included in the 8-SOIC (0.335, 8.50mm Width), Top Port package. The temperature of the transducers should be set to -40°C~125°C to ensure reliable performance. The transducers can operate well with a supply voltage of 4.64V~5.36V. The maximum pressure range set by this transducer is 58 Psi. This electronic component comes in the package of a Tape & Reel (TR).
MPXHZ6400AC6T1 Features
Moisture Sensitivity Level: 1 (Unlimited)
Package / Case: 8-SOIC (0.335, 8.50mm Width), Top Port
Operating Temperature: -40°C~125°C
MPXHZ6400A series
Sensitivity (mV/V): 12.1 mV/V
Operating Pressure: 2.9PSI ~ 58.02PSI (20kPa ~ 400kPa)
MPXHZ6400AC6T1 Applications
There are a lot of NXP USA Inc.
MPXHZ6400AC6T1 Transducers applications.
- General Purpose
- Process Control
- Altitude Control of Drones and Flying Toys
- Mobile Phones
- Virtual Reality and Gaming Equipment
- Indoor/Outdoor Navigation (dead-reckoning, floor/elevator/step detection)
- Vertical velocity monitoring
- Leisure, Sports, and Fitness Activity Identification
- Weather Forecasting
- Hydrogen Storage
