AM6CW-2415S-NZ-STD

Manufacturer :

Aimtec

Product Category :

Power (Watts) :

6W

Product Status :

Active

Voltage - Output 4 :

-

Minimum Load Required :

No

Height :

25.908 mm

Power Dissipation :

6 W

Max Operating Temperature :

85 °C

Max Output Current :

400 mA

Min Operating Temperature :

-40 °C

Output Power :

6 W

Efficiency :

88 %

Length :

75.946 mm

Output Voltage :

15 V

Approval Agency :

CE, cURus

Voltage - Isolation :

1.5 kV

Number of Outputs :

1

Voltage - Output 1 :

15V

Voltage - Output 5 :

-

Current - Output (Max) :

400mA

Max Input Voltage :

36 V

Base Product Number :

AM6CW

Isolation Voltage :

0 V

Mount :

DIN Rail, Screw

Standard Number :

60950-1

Package :

Box

Applications :

ITE (Commercial)

Switching Frequency :

300 kHz

Size / Dimension :

1.24 L x 1.02 W x 2.99 H (31.5mm x 25.9mm x 75.9mm)

Width :

31.496 mm

Weight :

56 g

RoHS :

Non-Compliant

Operating Temperature :

-40°C ~ 85°C

Features :

-

Min Input Voltage :

9 V

Voltage - Output 6 :

-

Series :

AM6CW-NZ (6W)

Voltage - Output 3 :

-

Input Type :

DC

Voltage - Output 2 :

15V
