PCH-112L2MH,000
Or copy the link below:
- Mfr.Part #
- PCH-112L2MH,000
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE SPST 5A 12V
- Stock
- 3,840
- In Stock ：
- 3,840
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Subcategory :
- Relays
- Packaging :
- Bulk
- Product Type :
- General Purpose Relays
- Mounting Style :
- Through Hole
- Features :
- Insulation - Class F, Sealed - Fully
- Seal Rating :
- Sealed - Fully
- Product Category :
- General Purpose Relays
- Number of Poles :
- 1
- Manufacturer :
- TE Connectivity
- Coil Current :
- 16.7mA
- Product Status :
- Active
- Length :
- 20mm
- Contact Configuration :
- SPST
- Coil Power :
- 200 mW
- Product :
- Power Relays
- Coil Voltage :
- 12VDC
- Contact Rating (Current) :
- 5A
- Application :
- PCB
- Height :
- 15.2mm
- Type :
- Miniature
- Terminal Type :
- Through Hole
- Contact Termination :
- Solder Pin
- Turn Off Voltage (Min) :
- 0.6 Vdc
- Switching Voltage :
- 277VAC, 30VDC - Max
- RoHS :
- Details
- Brand :
- TE Connectivity / PandB
- Contact Current Rating :
- 5 A
- Base Product Number :
- PCH-112
- Mounting Type :
- Through Hole
- Power Consumption :
- 200 mW
- Depth :
- 10mm
- Contact Material :
- Silver Tin Oxide (AgSnO)
- Moisture Sensitivity Level (MSL) :
- --
- Coil Insulation :
- Class F
- Release Time :
- 5ms
- Coil Type :
- Non Latching
- Package :
- Bulk
- Width :
- 10 mm
- Relay Type :
- GENERAL PURPOSE
- Turn On Voltage (Max) :
- 9 VDC
- Termination Style :
- PC Pin
- Switching Current :
- 5A
- Coil Resistance :
- 720 Ohms
- Contact Form :
- SPST-NO (1 Form A)
- Operate Time :
- 10ms
- Series :
- PCH, OEG
- Operating Temperature :
- -40°C ~ 85°C
- Must Release Voltage :
- 0.6 Vdc
- Must Operate Voltage :
- 9 VDC
- Datasheets
- PCH-112L2MH,000
PCH-112L2MH，000 datasheet pdf and Power Relays, Over 2 Amps product details from TE Connectivity stock available at
