PCH-124D2H,000
Or copy the link below:
- Mfr.Part #
- PCH-124D2H,000
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE SPDT 5A 24V
- Stock
- 53,357
- In Stock ：
- 53,357
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Compliance :
- C-UR-US, CSA, VDE
- Seal Rating :
- Sealed - Fully
- Supplier Package :
- Plastic Cover
- Coil Insulation :
- Class F
- Mounting :
- Through Hole
- Series :
- PCH, OEG
- Features :
- Insulation - Class F, Sealed - Fully
- Subcategory :
- Relays
- Turn Off Voltage (Min) :
- 1.2 VDC
- Contact Arrangement :
- SPDT
- Contact Rating (Current) :
- 5A
- Termination Style :
- PC Pin
- Length :
- 20 mm
- Coil Voltage :
- 24VDC
- Height :
- 15.2 mm
- Coil Type :
- Non Latching
- Mounting Type :
- Through Hole
- Product Length :
- 20 mm
- Must Release Voltage :
- 1.2 VDC
- Contact Current Rating :
- 5 A
- Turn On Voltage (Max) :
- 16.8 VDC
- Contact Termination :
- Solder Pin
- Minimum Dropout Voltage :
- 1.2 VDC
- Type :
- Standard
- Base Product Number :
- PCH-124
- Release Time :
- 5ms
- RoHS :
- Details
- Product Type :
- General Purpose Relays
- Switching Voltage :
- 277VAC, 30VDC - Max
- Contact Form :
- SPDT (1 Form C)
- Package :
- Bulk
- Coil Current :
- 16.7mA
- Product :
- Power Relays
- Relay Construction :
- Non-Latching
- Product Category :
- General Purpose Relays
- Moisture Sensitivity Level (MSL) :
- --
- Power Consumption :
- 400 mW
- Relay Type :
- GENERAL PURPOSE
- Must Operate Voltage :
- 16.8 VDC
- Coil Power :
- 400 mW
- Brand :
- TE Connectivity / OEG
- Coil Resistance :
- 1.44 kOhm
- Operating Temperature :
- -40 to 85 °C
- Mounting Style :
- Through Hole
- Contact Material :
- Silver Tin Oxide
- Packaging :
- Bulk
- Width :
- 10 mm
- Product Status :
- Active
- Operate Time :
- 10 ms
- Manufacturer :
- TE Connectivity
- Datasheets
- PCH-124D2H,000
PCH-124D2H000 datasheet pdf and Power Relays, Over 2 Amps product details from TE Connectivity stock available at
