10000

Manufacturer :

ASI-Ez

Product Category :

Interface Modules

Published :

2011

Mounting Type :

Free Hanging (In-Line), Right Angle

Factory Lead Time :

5 Weeks

Weight :

170.097139g

Orientation :

Keyed

Ratings :

Dust Tight, IP65, Water Resistant, Waterproof

Feature :

Backshell, Coupling Nut

Contact Material :

Copper Zinc

Shell Size - Insert :

M23-12

Color :

Silver

Voltage - Rated :

150V

Cable Opening :

0.315 ~ 0.472 (8.00mm ~ 12.00mm)

Series :

V

Mount :

Free Hanging

Number of Ports :

1

Contact Finish - Mating :

Gold

Housing Material :

Plastic

DIN Conformance :

No

Filter Feature :

No

Option :

GENERAL PURPOSE

Total Number of Contacts :

12

IEC Conformance :

No

Insert Material :

Polybutylene Terephthalate (PBT)

Connector Type :

Receptacle, Female Sockets

Shell Material :

Gadolinium-Zinc

Packaging :

Bulk

Backshell Type :

Solid

Current Rating :

8A

Shell Finish :

Nickel

Ingress Protection :

IP65/67 - Dust Tight, Water Resistant, Waterproof

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Material Flammability Rating :

UL94 V-0

Mixed Contacts :

No

Operating Temperature :

-20°C~80°C

Termination :

Solder Cup

Thread Size :

M23

Backshell Material, Plating :

Gadolinium-Zinc, Nickel

Empty Shell :

No

Contact Gender :

FEMALE

Number of Positions :

12

RoHS Status :

RoHS Compliant

MIL Conformance :

No

Fastening Type :

Threaded
