10070

Manufacturer :

Construction Resource Management, LLC

Product Category :

Min. permitted bending radius, moving application/free movement :

69

Width :

1.772 (45.00mm)

Package Cooled :

Assorted (BGA, LGA, CPU, ASIC...)

Series :

pushPIN™

Material outer sheath :

Polyvinyl Chloride (PVC)

Thermal Resistance @ Natural :

--

Material :

Aluminum

Outer diameter approx. :

9.2

Height Off Base (Height of Fin) :

0.590 (15.00mm)

Nominal voltage U :

500

Attachment Method :

Push Pin

Screen over stranding element :

NONE

Nominal voltage U0 :

300

Permitted cable outer temperature during assembling/handling :

-15 - 80

Type :

Top Mount

Stranding element :

No

Shape :

Square, Fins

Nominal cross section conductor :

1

Flame retardant :

According to IEC/EN 60332-1-2

Conductor category :

Class 5 = flexible

Colour outer sheath :

Grey

Material core insulation :

Polyvinyl Chloride (PVC)

Thermal Resistance @ Forced Air Flow :

15.31°C/W @ 100 LFM

Length :

1.772 (45.00mm)

Diameter :

--

Power Dissipation @ Temperature Rise :

--

Screen over stranding :

NONE

Core identification :

Numbers

Material Finish :

Blue Anodized

Low smoke (according to EN 61034-2) :

No

Permitted cable outer temperature after assembling without vibration :

-40 - 80

Min. permitted bending radius, stationary application/permanent installation :

37
