133088

Manufacturer :

Brady Corporation

Product Category :

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Height :

3.68mm

Max DC Current :

30mA

DC Resistance (DCR) :

60Ohm Max

Packaging :

Tape and Reel (TR)

Pbfree Code :

No

Packing Method :

TR, 7 INCH

Test Frequency :

790kHz

Quality Factor-Min (at L-nom) :

30

Height Seated (Max) :

0.145 3.68mm

Depth :

3.18mm

Inductor Type :

GENERAL PURPOSE INDUCTOR

Termination :

SMD/SMT

ECCN Code :

EAR99

Frequency - Self Resonant :

4.2MHz

Package / Case :

2-SMD

Published :

2010

Mount :

Surface Mount

Number of Pins :

2

Inductance :

680μH

Q Factor :

30

Current Rating :

30mA

Shape/Size Description :

RECTANGULAR PACKAGE

Series :

1330

Mounting Type :

Surface Mount

Terminal Shape :

WRAPAROUND

Material - Core :

Ferrite

Radiation Hardening :

No

Q @ Freq :

30 @ 790kHz

Number of Functions :

1

Size / Dimension :

0.313Lx0.115W 7.95mmx2.92mm

HTS Code :

8504.50.80.00

Number of Terminations :

2

Inductor Application :

RF INDUCTOR

Terminal Finish :

Tin/Lead (Sn/Pb)

Operating Temperature :

-55°C~105°C

Terminal Placement :

DUAL ENDED

RoHS Status :

Non-RoHS Compliant

JESD-609 Code :

e0

Shielding :

No

Factory Lead Time :

12 Weeks

Tolerance :

±1%
