1522

Manufacturer :

Global Specialties

Product Category :

Termination Type :

Wire Wrap

Contact Gender :

FEMALE

Contact Material :

COPPER ALLOY

Mount :

External

Accuracy :

1 %

Connector Type :

BOARD CONNECTOR

Length - Termination :

0.48 inch

Operating Temperature (Max) :

105°C

Insertion Force-Max :

3.0024 N

Reliability :

COMMERCIAL

Number of Rows :

2

Insulation Resistance :

1000000000Ohm

Height :

155mm

Frequency :

60Hz

RoHS Status :

Non-RoHS Compliant

Body Length or Diameter :

1.32 inch

Rated Current (Signal) :

3A

Weight :

5.5lbs 2.5kg

Dielectric Withstanding Voltage :

600VAC V

Operating Temperature (Min) :

-40°C

Withdrawl Force-Min :

.199882 N

Current Rating :

20A

Mating Contact Pitch :

0.1 inch

Body Depth :

0.433 inch

Contact Style :

SQ PIN-SKT

Plating Thickness :

FLASH inch

Terminal Pitch :

2.54mm

Insulator Color :

Black

Power Rating :

1.999kW

Width :

170mm

Contact Finish Termination :

Gold Over Nickel

Body Breadth :

0.197 inch

Contact Resistance :

20mOhm

Contact Pattern :

RECTANGULAR

PCB Contact Row Spacing :

2.54 mm

Wire/Cable Type :

Power Cord

Durability :

100 Cycles

Moisture Sensitivity Level (MSL) :

Not Applicable

Contact Finish - Mating :

AU ON NI

Tool Type :

Digital Wattmeter

PCB Contact Pattern :

RECTANGULAR

Reference Standard :

UL

Polarization Key :

POLARIZED HOUSING

Number Of PCB Rows :

2

Insulation Material :

Nylon

Total Number of Contacts :

26

Mating Contact Row Spacing :

0.1 inch

Number of Conductors :

ONE

Voltage - Rated AC :

115V
