19193-0062

Manufacturer :

Molex

Product Category :

Ring Connectors

Barrel Type :

Closed - Brazed

Product Status :

Active

Features :

-

Series :

19193

Terminal and Terminal Block Type :

RING TERMINAL

Gender :

FEMALE

Subcategory :

Terminals

Body Plating :

Tin

Contact Finish :

Electro-Tin

Package :

Box

Base Material :

Tin

Wire Gauge :

14-16(AWG)

Color :

Not Required

HTS Code :

8536.90.40.00

Pbfree Code :

yes

Terminal Type :

Circular

Mounting Angle :

Straight

Insulation Diameter :

-

Style :

Ring

Insulation Material :

NONE

Stud Size :

1-2 (M2)

Termination :

Crimp

ECCN Code :

EAR99

Product Category :

Terminals

Material :

Copper

Reach Compliance Code :

Compliant

Thickness :

0.031 (0.79mm)

Stud/Tab Size :

1, 2 Stud

Product Depth (mm) :

6.6(mm)

Body Material :

Copper

Product :

Screw Terminals

Tradename :

VersaKrimp

Package Type :

Bag

Wire Cross Section :

2 mm2

Termination Style :

Crimp

Width - Outer Edges :

0.250 (6.35mm)

Product Length (mm) :

14.2(mm)

Mounting Type :

Free Hanging (In-Line)

Type :

Ring Tongue Terminal

Brand :

Molex

Material - Insulation :

-

Contact Material :

Copper

Length - Overall :

0.560 (14.22mm)

Rad Hardened :

No

Length :

14.22 mm

Mounting Style :

Cable Mount / Free Hanging

Terminal Gender :

FEMALE

RoHS :

Details

Contact Plating :

Tin

Insulation :

Non-Insulated

Manufacturer :

Molex

Packaging :

Bag

Product Type :

Terminals
