1N5309

Manufacturer :

Solid State Inc.

Product Category :

Current Regulation - Diodes, Transistors

Case Connection :

Isolated

JESD-609 Code :

e0

RoHS Status :

Non-RoHS Compliant

Lifecycle Status :

IN PRODUCTION (Last Updated: 1 month ago)

Additional Feature :

METALLURGICALLY BONDED

Pin Count :

2

Operating Temperature (Max) :

175°C

Max Supply Voltage :

100V

Packaging :

Bulk

Power Dissipation-Max :

0.5W

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Elements :

1

Number of Terminations :

2

Qualification Status :

Not Qualified

ECCN Code :

EAR99

Regulation Current-Nom (Ireg) :

3mA

Dynamic Impedance-Min :

300000Ohm

Diode Element Material :

SILICON

Operating Temperature (Min) :

-65°C

Terminal Position :

END

Published :

1999

Terminal Finish :

TIN LEAD

Factory Lead Time :

20 Weeks

Mount :

Surface Mount

Diode Type :

CURRENT REGULATOR DIODE

JEDEC-95 Code :

DO-213AB

Pbfree Code :

No

HTS Code :

8541.10.00.70

Limiting Voltage-Max :

2.25V

Terminal Form :

WRAP AROUND

Element Configuration :

Single

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

JESD-30 Code :

O-LELF-R2
