1N5400-E3/73

Manufacturer :

Vishay

Product Category :

Diodes - Rectifiers - Single

Case Connection :

Isolated

Mounting Type :

Through Hole

Application :

GENERAL PURPOSE

Packaging :

Tape and Box (TB)

Number of Pins :

2

Mount :

Through Hole

Max Operating Temperature :

150°C

Additional Feature :

FREE WHEELING DIODE, LOW LEAKAGE CURRENT

Published :

2011

Radiation Hardening :

No

Speed :

Standard Recovery >500ns, > 200mA (Io)

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Element Configuration :

Single

Pin Count :

2

Max Reverse Voltage (DC) :

50V

Peak Non-Repetitive Surge Current :

200A

Forward Current :

3A

Diode Type :

Standard

Number of Phases :

1

Diode Element Material :

SILICON

Max Surge Current :

200A

Min Operating Temperature :

-50°C

Factory Lead Time :

18 Weeks

Reverse Voltage :

50V

RoHS Status :

ROHS3 Compliant

Operating Temperature - Junction :

-55°C~150°C

Number of Elements :

1

Peak Reverse Current :

5μA

Terminal Form :

Wire

Package / Case :

DO-201AD, Axial

HTS Code :

8541.10.00.80

Number of Terminations :

2

Base Part Number :

1N5400

Forward Voltage :

1.2V

ECCN Code :

EAR99

Output Current-Max :

3A

JESD-609 Code :

e3

Max Repetitive Reverse Voltage (Vrrm) :

50V

Voltage - Forward (Vf) (Max) @ If :

1.2V @ 3A

Capacitance @ Vr, F :

30pF @ 4V 1MHz

Average Rectified Current :

3A

Pbfree Code :

yes

Current - Reverse Leakage @ Vr :

5µA @ 50V

Terminal Finish :

Matte Tin (Sn)
