25336NLD

Manufacturer :

APEM Inc.

Product Category :

Body Height :

8.1mm

Switch Function :

On-On

Voltage - Rated AC :

30V

Dielectric Withstanding Voltage :

1000VRMS V

Mount :

PCB, Through Hole

Actuator Length :

2.30mm

Circuit :

SPDT

Series :

25000N

Contact (DC) Max Rating R Load :

.1A@30VDC

Actuator Type :

Standard

Mechanical Life :

20,000 Cycles

Current Rating (Amps) :

100mA DC

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Insulation Material :

Thermoplastic

Electrical Life :

10,000 Cycles

Packaging :

Bulk

HTS Code :

8536.50.90.50

Voltage - Rated DC :

30V

Orientation :

RIGHT ANGLE

Mounting Type :

Through Hole, Right Angle

Max Voltage Rating (AC) :

50mV

Factory Lead Time :

9 Weeks

Washability :

Partial

Sealing :

EPOXY TERMINAL SEALED

Switch Type :

SLIDE SWITCH

Number of Positions :

2

Length - Termination :

0.15 inch

ECCN Code :

EAR99

Contact Current Rating :

100mA

Termination :

PC Pin

Contact Current(DC)-Max :

0.1A

Solderability :

WAVE

Contact Material :

Brass

Termination Style :

PC Pin

Body Breadth :

7.5 mm

Actuator Material :

Polyamide (PA), Nylon, Glass Filled

Contact Resistance :

50mOhm

RoHS Status :

ROHS3 Compliant

Insulation Resistance :

1000000000Ohm

Current Rating :

100mA

Operating Temperature :

-40°C~85°C

Switch Travel :

4.00mm

Contact Timing :

NOT SPECIFIED

Max Voltage Rating (DC) :

30V

Feature :

Epoxy Sealed Terminals

Body Length or Diameter :

14.1mm

Number of Pins :

2

PCB Hole Count :

3

Housing Material :

Glass Filled Nylon

Contact Finish :

Gold
