304225

Manufacturer :

Elesa USA Corporation

Product Category :

Additional Feature :

STANDARDS: DIN 41612; IEC 60603-2

Body Depth :

0.457 inch

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Contact Finish Termination :

Tin

Contact Resistance :

20 mΩ

Total Number of Contacts :

32

Contact Gender :

Male

IEC Conformance :

yes

ECCN Code :

EAR99

PCB Contact Row Spacing :

2.54 mm

Mounting Style :

Straight

Mounting Type :

BOARD

Mixed Contacts :

No

Reach Compliance Code :

Unknown

Insulation Resistance :

1000000000000 Ω

UL Flammability Code :

94V-0

Terminal Length :

0.157 inch

Connector Type :

BOARD EURO CONNECTOR

Dielectric Withstanding Voltage :

1000VAC V

Insertion Force-Max :

.9452 N

Polarization Key :

HOUSING SIDE

MIL Conformance :

No

Name of Rows Loaded :

A,C

Number Of PCB Rows :

3

Reliability :

COMMERCIAL

Durability :

500 Cycles

Filter Feature :

No

Body Breadth :

0.433 inch

Mating Contact Pitch :

0.1 inch

JESD-609 Code :

e3

Mating Contact Row Spacing :

0.1 inch

Rated Current (Signal) :

1 A

Contact Style :

SQ PIN-SKT

Option :

GENERAL PURPOSE

Termination Type :

Solder

Body/Shell Style :

Receptacle

HTS Code :

8536.69.40.40

Terminal Pitch :

5.08 mm

Reference Standard :

UL, CSA

DIN Conformance :

yes

PCB Contact Pattern :

RECTANGULAR

Withdrawl Force-Min :

.9452 N
