3RS1800-2BW00

Manufacturer :

Siemens

Product Category :

Power Relays, Over 2 Amps

Relay Type :

GENERAL PURPOSE

Content :

1pc(s)

Number of contacts as normally open contact :

0

Must Release Voltage :

-

Must Operate Voltage :

-

Base Product Number :

3RS1800

RoHS-compliant :

yes

Coil Voltage :

24 ~ 240VAC/DC

Contact Form :

DPDT (2 Form C)

Coil Type :

Non Latching

Switching Voltage :

250VAC - Max

Coil Insulation :

-

Depth :

91mm

Number of contacts as normally closed contact :

0

Contact Rating (Current) :

3 A

Operating Temperature :

-25°C ~ 60°C

Features :

-

Product Status :

Active

Connection :

Spring-loaded connector

Contact Material :

-

Mounting Type :

DIN Rail

Seal Rating :

-

Manufacturer :

Siemens

Height :

94mm

Max. temperature :

+60°C

Type :

3RS1800-2BW00

RoHS :

Non-Compliant

Width :

22.5

Termination Style :

Spring Terminal

Min. temperature :

-25°C

Reach Compliance Code :

Unknown

Dim :

(W x H x D) 22.5 x 94 x 91 mm

Number of contacts as change-over contact :

2
