54F352DMQB

Manufacturer :

National Semiconductor

Product Category :

Signal Switches, Multiplexers, Decoders

Max I(ol) :

0.02 A

Propagation Delay (tpd) :

11 ns

JESD-30 Code :

R-GDIP-T16

Pin Count :

16

Number of Terminals :

16

Power Supply Current-Max (ICC) :

20mA

Logic IC Type :

Multiplexer

Power Supplies :

5V

Output Polarity :

INVERTED

Supply Voltage :

5V

Prop. Delay@Nom-Sup :

14 ns

Terminal Pitch :

2.54mm

Family :

F/FAST

Terminal Form :

THROUGH-HOLE

Temperature Grade :

Military

Terminal Position :

Dual

Number of Functions :

2

Operating Temperature (Min) :

-55°C

Supply Voltage-Min (Vsup) :

4.5V

Qualification Status :

Not Qualified

Screening Level :

38535Q/M;38534H;883B

Operating Temperature (Max) :

125°C

Number of Inputs :

4

Length :

19.43mm

Supply Voltage-Max (Vsup) :

5.5V

Seated Height-Max :

5.08mm

Width :

7.62mm

Number of Outputs :

1

HTS Code :

8542.39.00.01

Surface Mount :

No
