6EP44377FB003CX0

Manufacturer :

Siemens

Product Category :

Size / Dimension :

4.92 L x 1.77 W x 5.31 H (125.0mm x 45.0mm x 135.0mm)

Input Voltage :

20.4 → 30V

Accessory Type :

Selectivity Module

Product Status :

Active

Operating Temperature :

-25°C ~ 70°C

With detachable clamps :

No

Voltage - Output 3 :

-

Number of contacts as change-over contact :

0

Approval Agency :

CE, CSA, cULus, UL

Voltage - Output 4 :

-

Current - Output (Max) :

10A

Voltage - Output 1 :

23.8V

Output Current :

10A

Standard Number :

60950-1; UL 508

Efficiency :

98%

Voltage - Output 6 :

-

Input Type :

DC

Depth :

125

Height :

135

Type of electric connection :

Spring clamp connection

Number of contacts as normally open contact :

0

For Use With :

Siemens SITOP PSU6200 Power Supplies

Series :

SITOP

Number of Outputs :

1

Voltage - Output 5 :

-

Output Voltage :

24V

Minimum Load Required :

-

Applications :

Hazardous Locations, Industrial, ITE (Commercial)

Features :

Adjustable Output, IP20

Voltage - Output 2 :

-

Voltage type for actuating :

DC

Package :

Bulk

Rated control supply voltage at DC :

20.4 - 30

Number of contacts as normally closed contact :

0

Power (Watts) :

-

Width :

45
