7-6437630-0
Or copy the link below:
- Mfr.Part #
- 7-6437630-0
- Manufacturer
- TE Connectivity ALCOSWITCH Switches
- Package / Case
- Datasheet
- Download
- Description
- SWITCH TOGGLE SPDT 20A 125V
- Stock
- 17
- In Stock ：
- 17
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity ALCOSWITCH Switches
- Product Category :
- Contact Current Rating :
- 20 A
- Seal Location :
- ACTUATOR/PANEL/N/A
- Max Operating Temperature :
- 70 °C
- Voltage Rating - AC :
- 125V
- Panel Cutout Dimensions :
- Circular - 12.50mm Dia
- Ingress Protection :
- IP67 - Dust Tight, Waterproof
- Illumination Voltage (Nominal) :
- --
- Flammability Rating :
- UL94 V-0
- Current Rating (Max) :
- 20@250VAC 30VDC(A)
- Max Voltage Rating (DC) :
- 30 V
- Termination :
- Quick Connect
- Contact Material :
- Brass
- Actuator Type :
- Standard Round
- Current Rating :
- 20A (AC/DC)
- Mount :
- Bushing, Panel
- Thread Size :
- M12 x 1
- Circuit :
- SPDT
- REACH SVHC :
- No SVHC
- Termination Style :
- Quick Connect
- Product Status :
- Active
- Life (Cycles) :
- 20 kcycles
- Product Depth (mm) :
- 21(mm)
- Width :
- 33 mm
- Ratings :
- Dust Tight, IP67, Waterproof
- Operating Temperature Max Deg. C :
- 70C
- Illumination :
- Non-Illuminated
- Operating Temperature Min Deg. C :
- -20C
- Operating Force :
- 29.4 N
- Throw Configuration :
- SPDT
- Illumination Type, Color :
- --
- Dielectric Strength :
- 1500VAC
- AC Voltage Rating (Max) :
- 250
- Min Operating Temperature :
- -20 °C
- Switch Function :
- On-On
- Subcategory :
- Switches
- Product Height (mm) :
- 59.5(mm)
- Packaging :
- Bulk
- Current Rating (Amps) :
- 20A (AC/DC)
- Lead Free :
- Lead Free
- Number of Positions :
- 2
- Type :
- Power
- Actuator Style :
- Round Lever
- Height :
- 22.9 mm
- ELV :
- Compliant
- Mounting Type :
- Panel Mount
- DC Voltage Rating (Max) :
- 30
- Bushing Thread :
- M12 x 1
- Base Product Number :
- 6437630
- Length :
- 33 mm
- Voltage Rating - DC :
- 30V
- Body Orientation :
- Straight
- RoHS :
- Compliant
- Product Length (mm) :
- 33(mm)
- Series :
- AW
- Actuator Length :
- 17.50mm
- Manufacturer Lifecycle Status :
- ACTIVE (Last Updated: 1 week ago)
- Actuator Material :
- Brass
- Contact Resistance Max :
- 10(mohm)
- Contact Resistance :
- 10 MΩ
- Switch Configuration :
- ON ON
- Actuator Color :
- Chrome
- Product Type :
- Toggle Switches
- Voltage Rating (DC) :
- 30 V
- Radiation Hardening :
- No
- Max Voltage Rating (AC) :
- 250 V
- Electrical Life :
- 20000
- Pole Throw Configuration :
- SPDT
- Number of Terminals :
- 3
- Illumination Type :
- Illuminated, Non-Illuminated
- Orientation :
- Straight
- Mechanical Life :
- 40000
- Lifecycle Status :
- Production (Last Updated: 1 week ago)
- Operating Temp Range :
- -20C to 70C
- Contact Plating :
- BRASS SILVER ALLOY
- Features :
- --
- Depth :
- 21 mm
- Package :
- Bulk
- Bushing Type :
- Threaded
- Voltage Rating (AC) :
- 125 V
- Insulation Resistance :
- 1000(Mohm)
- Actuator Length (mm) :
- 17.5(mm)
- Operating Temperature :
- -20°C ~ 70°C
- Datasheets
