9-1415536-1
Or copy the link below:
- Mfr.Part #
- 9-1415536-1
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE DPDT 6A 24V
- Stock
- 8
- In Stock ：
- 8
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Coil Type :
- Non Latching
- Coil Resistance :
- 822 Ohms
- Packaging :
- Box
- Coil Voltage :
- 24VDC
- RoHS :
- Non-Compliant
- Contact Rating (Current) :
- 6A
- LED Indicator :
- yes
- Relay Type :
- General Purpose with Socket
- Seal Rating :
- -
- Must Operate Voltage :
- 21.6 VDC
- Switching Voltage :
- 250VAC - Max
- Pick-up Voltage (Max) :
- 21.6VDC
- Must Release Voltage :
- 2.4 VDC
- Coil Insulation :
- -
- Coil Suppression Diode :
- No
- Contact Termination :
- Spring Connectors
- Operating Temperature :
- -25°C ~ 50°C
- Coil Voltage DC :
- 24
- Contact Material :
- Silver Nickel
- Voltage Rating (VAC) :
- 250(V)
- Relay Construction :
- Non-Latching
- Base Product Number :
- 9-1415536
- Product Status :
- Active
- Package :
- Bulk
- Mounting Style :
- Din-Rail
- Mounting Type :
- DIN Rail
- Seal :
- Unsealed
- Contact Arrangement :
- DPDT
- Termination Style :
- Spring Terminal
- Contact Current Rating :
- 6(A)
- Coil Power :
- 700 mW
- Features :
- --
- Maximum Power Rating :
- 1.5KVA
- Dropout Volt :
- 2.4VDC
- Series :
- SR2Z, SCHRACK
- Rad Hardened :
- No
- Turn On Voltage (Max) :
- 21.6 VDC
- Coil Current :
- 29.2mA
- Operating Temp Range :
- -25C to 50C
- Contact Form :
- 2 Form C
- Turn Off Voltage (Min) :
- 2.4 VDC
- Datasheets
- 9-1415536-1
9-1415536-1 datasheet pdf and Power Relays, Over 2 Amps product details from TE Connectivity stock available at
You may place an order without registering to Xinshop. We strongly recommend that you log in before purchasing as you can track your order at any time.
RFQ (Request for Quotations)It is recommended to send RFQ to get the latest prices and stock availability about the part.Our sales will reply to your inquiry within 24 hours.
Payment MethodFor your convenience, we accept multiple payment methods in USD, Such as:PayPal, Credit Card, and wire transfer.
IMPORTANT NOTICEYou may place an order without registering to 1. You'll receive an order confirmations by e-mail soon . (Please remember to check the spam box if you didn't hear from us). 2. Since stock availability and prices may change at any time, the sales will reconfirm the order details and update you at soonest time.
Most of our products are shipped via FEDEX,DHL,UPS and SF EXPRESS...
Shipping CostShipping Cost starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.).If customer have shipping account, we can make shipment under customer’s shipping account with freight collect directly.
The basic freight (for package ≤0.5 KG ) depends on the time zones and countries
Once the goods are shipped, estimated delivery time depends on the shipping methods you chose. You can track it by the tracking no.
