A1001312

Manufacturer :

KYOCERA AVX

Product Category :

RF Antennas

Ingress Protection :

-

Product Status :

Active

Product :

PCB Antennas

Termination :

Solder

Impedance :

50 Ohms

Length :

2 mm

Mounting Type :

Surface Mount

Center Frequency :

2.443 GHz, 7.25 GHz

Cable Length :

-

Package :

Digi-Reel?

Frequency Group :

UHF (2GHz ~ 3GHz), SHF (f > 4GHz)

Height (Max) :

0.022" (0.55mm)

Series :

A

Antenna Type :

Chip

Frequency (Center/Band) :

2.4425GHz, 7.25GHz

Cable Type :

-

Minimum Operating Temperature :

- 50 C

RF Family/Standard :

802.15.4, Bluetooth, WiFi

Frequency Range :

2.4GHz ~ 2.485GHz, 6GHz ~ 8.5GHz

Bandwidth :

85 MHz, 2.5 GHz

Return Loss :

-

Application :

Wi-Fi Applications, Agriculture, Automotive, Healthcare, UWB

Applications :

Bluetooth, UWB, Wi-Fi, ZigBee

Subcategory :

Antennas

Polarization :

Linear

Style :

Chip

Antenna Connector Type :

-

Gain :

1.88dBi, 4.8dBi

Power Rating :

500 mW

Termination Style :

SMD/SMT

Product Type :

2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee

Height :

0.55 mm

Power - Max :

2 W

Features :

-

VSWR :

1.8, 2

Mounting Style :

PCB Mount

Number of Bands :

2

Maximum Operating Temperature :

+ 125 C

Width :

1.2 mm
