A8D10RA29CM233

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Edgeboard Connectors

PCB Contact Pattern :

RECTANGULAR

Mating Contact Pitch :

0.1 inch

Mounting Type :

BOARD

Dielectric Withstanding Voltage :

600VDC V

Mixed Contacts :

No

Reliability :

COMMERCIAL

Operating Temperature (Min) :

-40°C

Mounting Option 1 :

LOCKING

Number of Rows :

2

Withdrawl Force-Min :

.278 N

Terminal Pitch :

2.54mm

Plating Thickness :

30u inch

Contact Material :

NOT SPECIFIED

HTS Code :

8536.69.40.40

Mounting Style :

RIGHT ANGLE

RoHS Status :

Non-RoHS Compliant

Option :

GENERAL PURPOSE

Length - Termination :

0.14 inch

Reach Compliance Code :

Compliant

Mating Contact Row Spacing :

0.15 inch

Reference Standard :

UL

Contact Pattern :

RECTANGULAR

Connector Type :

CARD EDGE CONNECTOR

DIN Conformance :

No

Filter Feature :

No

Total Number of Contacts :

10

Contact Style :

BELLOWED TYPE

Body Depth :

0.73 inch

Contact Gender :

FEMALE

UL Flammability Code :

94V-0

PCB Contact Row Spacing :

3.81 mm

Board Mounting Option :

HOLE .125-.137

Insulator Color :

Black

ECCN Code :

EAR99

Rated Current (Signal) :

3A

Termination Type :

Solder

Body Length or Diameter :

1.835 inch

Contact Finish - Mating :

NOT SPECIFIED

Body/Shell Style :

Receptacle

Insertion Force-Max :

1.112 N

MIL Conformance :

No

Insulation Resistance :

5000000000Ohm

Insulation Material :

GLASS FILLED THERMOPLASTIC

Body Breadth :

0.368 inch

IEC Conformance :

No

Number of Conductors :

ONE

Number Of PCB Rows :

2

Operating Temperature (Max) :

100°C
