AD22037Z
Or copy the link below:
- Mfr.Part #
- AD22037Z
- Manufacturer
- Analog Devices, Inc.
- Package / Case
- 8-CLCC
- Datasheet
- Download
- Description
- ACCELEROMETER 18G ANALOG 8CLCC
- Stock
- 1,977
- In Stock ：
- 1,977
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Analog Devices, Inc.
- Product Category :
- Motion Sensors - Accelerometers
- -3db Bandwidth :
- 2.5 kHz
- Lead Free :
- Contains Lead
- Contact Plating :
- Gold
- Supply Voltage-Min (Vsup) :
- 3V
- Terminal Pitch :
- 1.27mm
- Lifecycle Status :
- Production (Last Updated: 1 week ago)
- Terminal Position :
- QUAD
- Output Type :
- Analog Voltage
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Number of Pins :
- 8
- Operating Temperature :
- -40°C~125°C TA
- Pbfree Code :
- No
- Supply Voltage-Max (Vsup) :
- 6V
- Depth :
- 5mm
- Voltage - Supply :
- 3V~6V
- Acceleration Range :
- ±18g
- Feature :
- Adjustable Bandwidth
- Pin Count :
- 8
- Sensitivity (mV/G) :
- 100
- Factory Lead Time :
- 10 Weeks
- Nominal Supply Current :
- 700µA
- Surface Mount :
- yes
- Length :
- 5mm
- Packaging :
- Tube
- Axis :
- X, Y
- Bandwidth :
- 0.5Hz ~ 2.5kHz
- Supply Voltage :
- 5V
- Type :
- Analog
- Number of Functions :
- 1
- Radiation Hardening :
- No
- Height :
- 1.95mm
- ECCN Code :
- EAR99
- RoHS Status :
- ROHS3 Compliant
- Series :
- iMEMS®
- REACH SVHC :
- No SVHC
- Package / Case :
- 8-CLCC
- Mounting Type :
- Surface Mount
- Width :
- 5.15mm
- Number of Terminations :
- 8
- Power Supplies :
- 5V
- Datasheets
- AD22037Z
AD22037Z datasheet pdf and Motion Sensors - Accelerometers product details from Analog Devices Inc. stock available at
LM2575HVT-5.0/NOPB Description
The ADXL103/ADXL203 are high precision, low power, complete single- and dual-axis accelerometers with signal-conditioned voltage outputs, all on a single, monolithic IC. The ADXL103/ ADXL203 measures acceleration with a full-scale range of ±1.7 g, ±5 g, or ±18 g. The ADXL103/ADXL203 can measure both dynamic acceleration (for example, vibration) and static acceleration (for example, gravity). The typical noise floor is 110 μg/√Hz, allowing signals below 1 mg (0.06° of inclination) to be resolved in tilt sensing applications using narrow bandwidths (<60 Hz). The user selects the bandwidth of the accelerometer using Capacitor CX and Capacitor CY at the XOUT and YOUT pins. Bandwidths of 0.5 Hz to 2.5 kHz can be selected to suit the application. The ADXL103 and ADXL203 are available in a 5 mm × 5 mm × 2 mm, 8-terminal ceramic LCC package.
LM2575HVT-5.0/NOPB Features
High-performance, single-/dual-axis accelerometer on
a single IC chip
5 mm × 5 mm × 2 mm LCC package
1 mg resolution at 60 Hz
Low power: 700 μA at VS = 5 V (typical)
High zero-g bias stability
High sensitivity accuracy
−40°C to +125°C temperature range
X and Y axes aligned to within 0.1° (typical)
Bandwidth adjustment with a single capacitor
Single-supply operation
3500 g shock survival
RoHS compliant
Compatible with Sn/Pb- and Pb-free solder processes
Qualified for automotive applications
LM2575HVT-5.0/NOPB Applications
Vehicle dynamic controls
Electronic chassis controls
Platform stabilization/leveling
Navigation
Alarms and motion detectors
High accuracy, 2-axis tilt sensing
Vibration monitoring and compensation
Abuse event detection
