AD7888ARU

Manufacturer :

Precision Monolithics

Product Category :

Analog to Digital Converters (ADC)

Peak Reflow Temperature (Cel) :

260

Terminal Position :

Dual

Pin Count :

16

ECCN Code :

EAR99

Number of Analog In Channels :

8

Conversion Time-Max :

7.25μs

Packaging :

Tube

Reference Type :

External, Internal

Pbfree Code :

No

Ratio - S/H:ADC :

1:1

Power Dissipation :

3.5mW

Supply Type :

Single

Terminal Form :

Gull wing

Converter Type :

ADC, SUCCESSIVE APPROXIMATION

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Data Interface :

SPI, DSP

Mounting Type :

Surface Mount

Nominal Supply Current :

700µA

Number of Channels :

8

Integral Nonlinearity (INL) :

2 LSB

Max Input Voltage :

5.25V

Voltage - Supply, Digital :

2.7V~5.25V

Differential Nonlinearity :

2 LSB

Surface Mount :

yes

Radiation Hardening :

No

Time@Peak Reflow Temperature-Max (s) :

40

REACH SVHC :

No SVHC

Max Supply Voltage :

5.25V

Operating Temperature :

-40°C~105°C

Input Capacitance :

38pF

Input Type :

Single Ended

Output Bit Code :

BINARY

Contact Plating :

Tin

Output Format :

Serial

Sampling Rate (Per Second) :

125k

Min Supply Voltage :

2.7V

Width :

4.4mm

Polarity :

Unipolar

RoHS Status :

ROHS3 Compliant

Resolution :

1.5 B

Number of Pins :

16

Min Input Voltage :

2.5V

Base Part Number :

AD7888

Voltage - Supply, Analog :

2.7V~5.25V

Sample and Hold / Track and Hold :

TRACK

Number of Elements :

1

Number of Terminations :

16

Configuration :

MUX-S/H-ADC

Package / Case :

16-TSSOP (0.173, 4.40mm Width)

Signal to Noise Ratio (SNR) :

71 dB

Lifecycle Status :

Production (Last Updated: 4 weeks ago)

Interface :

SPI

Number of A/D Converters :

1

Operating Supply Voltage :

5V

Sampling Rate :

125 ksps

Factory Lead Time :

10 Weeks

Lead Free :

Contains Lead

JESD-609 Code :

e3

Max Power Dissipation :

3.5mW

Number of Functions :

1

Length :

5mm

Architecture :

SAR

Height :

1.05mm

Number of Bits :

12
