AS1100

Manufacturer :

Neer

Product Category :

Package / Case :

24-SOIC (0.295, 7.50mm Width)

Max Supply Current :

500μA

Height Seated (Max) :

2.65mm

Interface :

Serial

Display Type :

LED

Factory Lead Time :

16 Weeks

Min Input Voltage :

4V

Output Current :

320mA

Supply Voltage :

5V

Peak Reflow Temperature (Cel) :

260

Operating Supply Voltage :

5V

Lead Free :

Lead Free

Configuration :

7 Segment + DP

Additional Feature :

BARGRAPH

REACH SVHC :

No SVHC

Switching Frequency :

10MHz

Number of Terminations :

24

Qualification Status :

Not Qualified

Terminal Position :

Dual

Terminal Form :

Gull wing

Output Voltage :

7V

Number of Pins :

24

Number of Segments :

7

Operating Temperature :

0°C~70°C

Max Input Voltage :

5.5V

JESD-609 Code :

e0

Voltage - Supply :

4V~5.5V

Weight :

1.098005g

Power Supplies :

5V

Pin Count :

24

Surface Mount :

yes

Time@Peak Reflow Temperature-Max (s) :

40

Digits or Characters :

8 Digits

Multiplexed Display Capability :

yes

RoHS Status :

RoHS Compliant

Terminal Finish :

Tin/Lead (Sn/Pb)

Number of Outputs :

16

HTS Code :

8542.39.00.01

Packaging :

Tube

Operating Supply Current :

330mA

Pbfree Code :

No

Number of Functions :

1

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Max Power Dissipation :

941mW

Length :

15.4mm

Mounting Type :

Surface Mount

ECCN Code :

EAR99

Current Rating :

40mA
