AT42QT1010-MAHR

Manufacturer :

Microchip Technology

Product Category :

Sensor, Capacitive Touch

Max Operating Temperature :

85 °C

Maximum Operating Temperature :

+85 °C

Number of Functions :

1

Number of Terminations :

8

LED Driver Channels :

--

Supply Voltage :

3V

Width :

2mm

Package / Case :

8-UFDFN Exposed Pad

Terminal Form :

NO LEAD

Published :

1997

Subcategory :

Sensors

Length :

2mm

Lifecycle Status :

Production (Last Updated: 2 years ago)

Termination Style :

SMD/SMT

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Reach Compliance Code :

Compliant

Analog IC - Other Type :

ANALOG CIRCUIT

Supply Voltage-Max (Vsup) :

5.5V

Interface Type :

Digital Output

Number of Channels :

1 Channel

Number of Inputs :

1

Resolution :

14 b

Type :

Buttons

Base Product Number :

AT42QT1010

Seated Height-Max :

0.65 mm

Voltage - Supply :

1.8V~5.5V

Factory Lead Time :

7 Weeks

Packaging :

Tape and Reel (TR)

Operating Temperature :

-40°C~85°C

Brand :

Microchip Technology / Atmel

Max Supply Voltage :

5.5 V

MSL :

MSL 1 - Unlimited

Package Type :

UDFN/USON

Height :

0.55mm

Dimensions :

2.05 x 2 x 0.55mm

Supplier Device Package :

8-UDFN, USON

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

JESD-30 Code :

S-PDSO-N8

Number of Terminals :

8

Product Category :

Capacitive Touch Sensors

Pbfree Code :

yes

Current - Supply :

378.5µA

Series :

QTouch™

Minimum Operating Temperature :

-40 °C

Operating Supply Voltage :

1.8 V to 5.5 V

Proximity Detection :

yes

Product Type :

Touch Sensors

RoHS :

Details

RoHS Status :

ROHS3 Compliant

Min Supply Voltage :

1.8 V

Package Shape :

Square

Interface :

--

Manufacturer :

Microchip

Terminal Pitch :

0.5mm

Typical Operating Supply Voltage :

1.8 V

Min Operating Temperature :

-40 °C

Surface Mount :

yes

Height Seated (Max) :

0.65mm

Terminal Position :

Dual

Sensor Type :

Touch Screen Controllers

Temperature Grade :

Industrial

Mounting Type :

Surface Mount

Pin Count :

8

Schedule B :

8542310000

Product Status :

Active

Supply Voltage-Min (Vsup) :

1.8 V
