ATMEGA128-16AC

Manufacturer :

Atmel (Microchip Technology)

Product Category :

Microcontrollers

External Data Bus Width :

8

Memory Type :

Flash

Base Product Number :

ATMEGA128

Subcategory :

Microcontrollers

RoHS :

Non-Compliant

Number of I/O :

53

Core Size :

8-Bit

Number of Terminals :

64

uPs/uCs/Peripheral ICs Type :

MICROCONTROLLER, RISC

Temperature Grade :

COMMERCIAL

Factory Lead Time :

1 Week

Terminal Position :

QUAD

Qualification Status :

Not Qualified

Mounting Type :

Surface Mount

Supplier Device Package :

64-TQFP (14x14)

Peripherals :

Brown-out Detect/Reset, POR, PWM, WDT

Access Time :

16 μs

Max Operating Temperature :

70°C

Has ADC :

yes

ROM Programmability :

Flash

Max Supply Voltage :

5.5V

Speed :

16MHz

Series :

AVR® ATmega

CPU Family :

AVR RISC

Number of I/O Lines :

53

Program Memory Size :

128KB 64K x 16

Address Bus Width :

16

PWM Channels :

yes

Program Memory Type :

Flash

Oscillator Type :

Internal

Pin Count :

64

Memory Size :

128kB

EEPROM Size :

4K x 8

Bit Size :

8

Connectivity :

EBI/EMI, I2C, SPI, UART/USART

Surface Mount :

yes

Package / Case :

64-TQFP

Core Architecture :

AVR

Power Supplies :

5 V

Lead Free :

Contains Lead

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Length :

14 mm

Min Operating Temperature :

0°C

Terminal Finish :

Tin/Lead (Sn/Pb)

DAC Channels :

No

Number of I/Os :

53

Data Bus Width :

8B

Min Supply Voltage :

4.5V

DMA Channels :

No

RoHS Status :

Non-RoHS Compliant

Product Status :

Obsolete

Operating Temperature :

0°C~70°C TA

Width :

14 mm

Terminal Form :

Gull wing

Frequency :

16MHz

Number of Timers/Counters :

4

JESD-609 Code :

e0

Data Converter :

A/D 8x10b

Published :

1997

Reach Compliance Code :

Compliant

RAM Size :

4K x 8

Interface :

2-Wire, EBI/EMI, I2C, SPI, UART, USART

Peak Reflow Temperature (Cel) :

240

Package :

Tray

Data Converters :

A/D 8x10b

ROM (words) :

65536

Core Processor :

AVR

HTS Code :

8542.31.00.01

JESD-30 Code :

S-PQFP-G64

Base Part Number :

ATMEGA128

RAM (bytes) :

4096

Technology :

CMOS

Voltage - Supply (Vcc/Vdd) :

4.5V~5.5V

Seated Height-Max :

1.2 mm

Packaging :

Tray

Number of Pins :

64

Number of Programmable I/O :

53

Terminal Pitch :

0.8 mm

Manufacturer :

Atmel Corporation

Mount :

Surface Mount

Max Frequency :

16MHz

Package Shape :

Square
