BZY55C20 RYG

Manufacturer :

Taiwan Semiconductor

Product Category :

Diodes - Zener - Single

HTS Code :

8541.10.00.50

JESD-30 Code :

R-PDSO-R2

Operating Temperature :

-55°C~150°C TJ

Factory Lead Time :

26 Weeks

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Elements :

1

RoHS Status :

ROHS3 Compliant

Voltage - Forward (Vf) (Max) @ If :

1.5V @ 10mA

Diode Type :

ZENER DIODE

Qualification Status :

Not Qualified

Polarity :

Unidirectional

Power - Max :

500mW

Tolerance :

±5%

Configuration :

Single

Reference Voltage :

20V

Voltage - Zener (Nom) (Vz) :

20V

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Power Dissipation-Max :

0.5W

Terminal Form :

WRAP AROUND

Terminal Position :

Dual

Current - Reverse Leakage @ Vr :

100nA @ 15V

Impedance-Max :

55Ohm

Package / Case :

0805 (2012 Metric)

JESD-609 Code :

e3

Terminal Finish :

Matte Tin (Sn)

Mounting Type :

Surface Mount

ECCN Code :

EAR99

Working Test Current :

5mA

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Surface Mount :

yes

Number of Terminations :

2

Packaging :

Tape and Reel (TR)

Voltage Tol-Max :

2%

Diode Element Material :

SILICON
