CAT3647HV3-GT2

Manufacturer :

Catalyst Semiconductor Inc.

Product Category :

LED Drivers

Voltage - Supply (Max) :

5.5V

Number of Functions :

1

Number of Segments :

3

JESD-30 Code :

S-XQCC-N16

Terminal Pitch :

0.5mm

Mounting Type :

Surface Mount

Voltage - Supply (Min) :

2.5V

Pbfree Code :

yes

Applications :

Backlight

Data Input Mode :

Serial

JESD-609 Code :

e4

Frequency :

1MHz~1.3MHz

Time@Peak Reflow Temperature-Max (s) :

40

Supply Voltage :

3.6V

Qualification Status :

COMMERCIAL

Internal Switch(s) :

yes

Number of Outputs :

3

Terminal Position :

QUAD

Peak Reflow Temperature (Cel) :

260

Dimming :

Multi-Step

Current - Output / Channel :

30mA

Multiplexed Display Capability :

No

Terminal Form :

NO LEAD

Reach Compliance Code :

Unknown

Number of Terminations :

16

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Height Seated (Max) :

0.8mm

Surface Mount :

yes

Topology :

Switched Capacitor (Charge Pump)

Packaging :

Tape and Reel (TR)

RoHS Status :

ROHS3 Compliant

Operating Temperature :

-40°C~85°C TA

Pin Count :

16

Package / Case :

16-WFQFN Exposed Pad

Terminal Finish :

NICKEL PALLADIUM GOLD

Type :

DC DC Regulator
