DAC70501MDGSR

Manufacturer :

Texas Instruments

Product Category :

Digital to Analog Converters (DAC)

Terminal Form :

Gull wing

Data Interface :

I2C, SPI

Surface Mount :

yes

Factory Lead Time :

6 Weeks

Voltage - Supply, Analog :

2.7V~5.5V

Input Bit Code :

BINARY

Number of Bits :

14

Package / Case :

10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Converter Type :

D/A CONVERTER

Number of D/A Converters :

1

Number of Terminations :

10

Number of Functions :

1

Moisture Sensitivity Level (MSL) :

2 (1 Year)

Output Type :

Voltage - Buffered

Base Part Number :

DAC70501

Terminal Position :

Dual

Differential Output :

No

INL/DNL (LSB) :

±1 (Max), ±1 (Max)

Settling Time :

5µs (Typ)

Width :

3mm

Terminal Pitch :

0.5mm

Input Format :

Serial

Analog Output Voltage-Max :

5.5V

RoHS Status :

ROHS3 Compliant

Length :

3mm

Architecture :

R-2R

Supply Voltage :

5V

Operating Temperature :

-40°C~125°C

Pbfree Code :

yes

Voltage - Supply, Digital :

2.7V~5.5V

Mounting Type :

Surface Mount

Reference Type :

External, Internal
