DRS-240-24

Manufacturer :

MEAN WELL

Product Category :

Modulation :

-

Voltage - Output 3 :

-

Width :

85.5 mm

Package :

Tape and Reel (TR)

Sensitivity :

-

Maximum Operating Temperature :

+ 70 C

Mounting Style :

DIN Rail Mount

Features :

Adjustable Output, PFC, PMBus™

Minimum Load Required :

-

Voltage - Output 1 :

24V

Power (Watts) :

240W

Data Rate :

375kbps

Product :

Switching Supplies

Minimum Operating Temperature :

- 30 C

Efficiency :

92%

Voltage - Isolation :

4 kV

Length :

129.2 mm

Serial Interfaces :

ADC, GPIO, UART, USB

Standard Number :

62368-1

Voltage - Output 4 :

-

Voltage - Output 2 :

-

Frequency :

-

Product Status :

Discontinued at Digi-Key

Protocol :

LTE, GNSS

Voltage - Supply :

-

RF Family/Standard :

Cellular, Navigation

Input Type :

AC or DC

Power - Output :

-

Approval Agency :

CB, CE, cURus, EAC, UKCA

Applications :

ITE (Commercial)

Current - Transmitting :

-

Manufacturer :

Mean Well

Mounting Type :

Surface Mount

Memory Size :

-

Current - Receiving :

-

Package / Case :

86-BFLGA Module

Current - Output (Max) :

10A

Utilized IC / Part :

-

Input Voltage :

90 VAC to 305 VAC, 127 VDC to 431 VDC

Product Category :

DIN Rail Power Supplies

Size / Dimension :

5.09 L x 3.37 W x 4.93 H (129.2mm x 85.5mm x 125.2mm)

Subcategory :

AC-DC Power Supply

Voltage - Output 6 :

-

Product Type :

DIN Rail Power Supplies

Height :

125.2 mm

Voltage - Output 5 :

-

Number of Outputs :

1 Output

Series :

HL

Output Power :

240 W

RoHS :

Details

Brand :

Mean Well

Antenna Type :

Antenna Not Included

Operating Temperature :

-40°C ~ 85°C
