GX434--CKC

Manufacturer :

Gennum

Product Category :

Analog Switches - Special Purpose

Temperature Grade :

COMMERCIAL

Operating Temperature :

0°C ~ 70°C (TA)

On-State Resistance (Max) :

-

HTS Code :

8542.39.00.01

Qualification Status :

Not Qualified

Series :

-

Manufacturer :

Gennum Corporation

Terminal Form :

Gull wing

Applications :

Video

Package / Case :

16-SOIC

Subcategory :

Multiplexer or Switches

Number of Functions :

1

JESD-30 Code :

R-PDSO-G16

Product Status :

Active

-3db Bandwidth :

120MHz

Package :

Bulk

Package Shape :

RECTANGULAR

Terminal Pitch :

1.27 mm

Number of Channels :

1

Technology :

Bipolar

Voltage - Supply, Dual (V±) :

7V ~ 13.2V

Switch Circuit :

4PST

Multiplexer/Demultiplexer Circuit :

4:1

Voltage - Supply, Single (V+) :

7V ~ 13.2V

Terminal Position :

Dual

Power Supplies :

+-8 V

RoHS :

Non-Compliant

Switch-on Time-Max :

270 ns

Off-state Isolation-Nom :

110 dB

Analog IC - Other Type :

VIDEO MULTIPLEXER

Surface Mount :

yes

Reach Compliance Code :

Unknown

Signal Current-Max :

0.00005 A

Supply Current-Max (Isup) :

11.5 mA

Number of Terminals :

16

Supplier Device Package :

16-SOIC

Neg Supply Voltage-Nom (Vsup) :

-8 V

Features :

-

Switch-off Time-Max :

800 ns

Pin Count :

16
