H12D4875H

Manufacturer :

Sensata Technologies – Crydom

Product Category :

Solid State Relays

Optoelectronic Device Type :

TRIGGER OUTPUT SSR

Circuit :

1NO

Input Polarity :

DC

Reach Compliance Code :

Compliant

Current Rating :

75 A

Manufacturer :

Crydom

Termination :

Screw Terminal

Output Circuit Type :

Back to Back SCR

Additional Feature :

UL RECOGNIZED, VDE APPROVED, ZERO VOLTAGE CROSSING

Number of Elements :

1

Overall Height :

23mm

On-State Current-Max :

75A

Output Voltage :

48-530 VAC

Operating Temperature (Max) :

80°C

Nominal Output Voltage :

48 VAC, 120 VAC, 208 VAC, 240 VAC, 277 VAC, 347 VAC, 380 VAC, 415 VAC, 480 VAC, 575 VAC

HTS Code :

8541.40.95.00

Control Voltage :

4V

Overall Length :

58.4mm

RoHS Status :

RoHS Compliant

Input Type :

DC

Number of Circuits :

1

Operating Temperature (Min) :

-40°C

Mounting :

Surface

Isolation Voltage-Max :

4000V

Input Signal :

4-32 VDC, 12 VDC, 24 VDC

Output Type :

SCR AC Switch
