HC3-1R0-R
Or copy the link below:
- Mfr.Part #
- HC3-1R0-R
- Manufacturer
- Eaton-Electronics Division
- Package / Case
- Nonstandard
- Datasheet
- Download
- Description
- FIXED IND 1UH 78A 0.42 MOHM SMD
- Stock
- 298
- In Stock ：
- 298
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Eaton-Electronics Division
- Product Category :
- Fixed Inductors
- Material - Core :
- Ferrite
- RoHS Status :
- RoHS Compliant
- Min Operating Temperature :
- -40°C
- DC Resistance (DCR) :
- 0.42mOhm Max
- Test Frequency :
- 300kHz
- REACH SVHC :
- Unknown
- Operating Temperature :
- -40°C~85°C
- Inductance Frequency - Test :
- 300kHz
- Current Rating (Amps) :
- 78A
- Weight :
- 42.637683g
- Inductance Tolerance :
- 20%
- Max DC Current :
- 78A
- Lead Free :
- Lead Free
- Series :
- HC3
- Type :
- Wirewound
- Mount :
- Surface Mount
- Mounting Type :
- Surface Mount
- Height :
- 17.5mm
- Length :
- 29.9974mm
- Tolerance :
- ±20%
- Package / Case :
- Nonstandard
- Composition :
- Wirewound
- Size / Dimension :
- 1.181Lx0.996W 30.00mmx25.30mm
- Depth :
- 25.3mm
- Factory Lead Time :
- 15 Weeks
- Number of Pins :
- 2
- Current - Saturation :
- 78A
- Current Rating :
- 78A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Published :
- 2015
- Max Operating Temperature :
- 85°C
- Inductance :
- 1μH
- RMS Current (Irms) :
- 78A
- Military Standard :
- Not
- Radiation Hardening :
- No
- Packaging :
- Bulk
- Width :
- 25.2984mm
- Shielding :
- Unshielded
- Height Seated (Max) :
- 0.689 17.50mm
- Termination :
- SMD/SMT
- Datasheets
- HC3-1R0-R
