HSP50306SC-25

Manufacturer :

Intersil

Product Category :

RF Demodulators

Package Shape :

RECTANGULAR

Function :

Demodulator, Detector

Manufacturer :

Rochester Electronics LLC

RoHS :

Non-Compliant

Qualification Status :

Not Qualified

P1dB :

-

Temperature Grade :

COMMERCIAL

Terminal Finish :

TIN LEAD

Seated Height-Max :

2.65 mm

Series :

-

HTS Code :

8542.39.00.01

JESD-609 Code :

e0

Reach Compliance Code :

Unknown

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Terminal Pitch :

1.27 mm

Number of Functions :

1

Product Status :

Active

Package / Case :

16-SOIC (0.295", 7.50mm Width)

Package :

Bulk

Supplier Device Package :

16-SOIC

RF Frequency :

-

Number of Terminals :

16

Length :

10.3 mm

Pbfree Code :

No

Noise Figure :

-

Gain :

-

JESD-30 Code :

R-PDSO-G16

Current - Supply :

114 mA

Pin Count :

16

LO Frequency :

-

Terminal Position :

Dual

Voltage - Supply :

4.75V ~ 5.25V

Width :

7.5 mm

Telecom IC Type :

TELECOM CIRCUIT

Mounting Type :

Surface Mount

Terminal Form :

Gull wing

Surface Mount :

yes
