JSM1-12V-5
Or copy the link below:
- Mfr.Part #
- JSM1-12V-5
- Manufacturer
- CTR Electronics
- Package / Case
- Datasheet
- Download
- Description
- RELAY AUTOMOTIVE SPDT 15A 12V
- Stock
- 9,796
- In Stock ：
- 9,796
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- CTR Electronics
- Product Category :
- Automotive Relays
- Switching Voltage :
- 16VDC -Max
- Ratings :
- IP67
- Factory Lead Time :
- 16 Weeks
- Contact Material :
- Silver Alloy, Cadmium Free
- Width :
- 16.4mm
- Contact Form :
- SPDT (1 Form C)
- RoHS Status :
- RoHS Compliant
- Relay Type :
- Automotive
- Height :
- 16.8mm
- Termination Style :
- PC Pin
- Relay Action :
- Momentary
- Coil Voltage (DC) :
- 12V
- Hole Diameter :
- 1.3 mm
- Coil Type :
- Non Latching
- Test Voltage :
- 1.5kV
- Must Operate Voltage :
- 6.3VDC
- Switching Current :
- 15A
- ECCN Code :
- EAR99
- Voltage - Rated DC :
- 16V
- Contact/Output Supply Type :
- DC
- Mount :
- PCB, Through Hole
- Coil Current :
- 53.3mA
- Coil Resistance :
- 225Ohm
- Current Rating :
- 15A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Number of Pins :
- 5
- Operating Temperature :
- -40°C~85°C
- Ambient Temperature Range High :
- 85°C
- Radiation Hardening :
- No
- Pbfree Code :
- yes
- Feature :
- Sealed - Fully
- Power Consumption :
- 640mW
- Max Voltage Rating (DC) :
- 16V
- Coil Voltage :
- 12VDC
- Max Current Rating :
- 15A
- REACH SVHC :
- No SVHC
- Series :
- JS-M
- Number of Contacts :
- 1
- Switching Capacity :
- 160 W
- Throw Configuration :
- SPDT
- Depth :
- 16mm
- Coil/Input Supply Type :
- DC
- Power Rating :
- 640mW
- Packaging :
- Bulk
- Lead Free :
- Lead Free
- Termination :
- PC Pin
- Must Release Voltage :
- 0.9VDC
- Weight :
- 12g
- Operate Time :
- 10ms
- Mounting Type :
- Through Hole
- Length :
- 22mm
- Published :
- 1999
- Datasheets
- JSM1-12V-5
JSM1-12V-5 datasheet pdf and Automotive Relays product details from Panasonic Electric Works stock available at
Features:
- Single-pole changeover (SPCO) relay
- 12V DC voltage rating
- 15A current rating
- PCB-mountable
- Designed for automotive applications
Applications: The Panasonic EW JSM1-12V-5 Relay is suitable for use in automotive applications such as power windows, door locks, and lighting systems. It can also be used in other applications where a 12V DC voltage and 15A current rating are required.
