LTC2654IUF-H12#PBF
Or copy the link below:
- Mfr.Part #
- LTC2654IUF-H12#PBF
- Manufacturer
- Linear Technology
- Package / Case
- 20-WFQFN Exposed Pad
- Datasheet
- Download
- Description
- LTC2654 - 12-BIT SPI QUAD DAC
- Stock
- 42,510
- In Stock ：
- 42,510
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Linear Technology
- Product Category :
- Digital to Analog Converters (DAC)
- Output Type :
- Voltage - Buffered
- Interface :
- SPI, Serial
- Data Interface :
- SPI
- Number of Functions :
- 1
- RoHS Status :
- ROHS3 Compliant
- Reference Type :
- External, Internal
- Input Bit Code :
- BINARY
- Packaging :
- Tube
- Converter Type :
- D/A CONVERTER
- Mounting Type :
- Surface Mount
- Settling Time :
- 4.2µs (Typ)
- Power Supplies :
- 5V
- Mount :
- Surface Mount
- Peak Reflow Temperature (Cel) :
- 260
- Number of Pins :
- 20
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Published :
- 2010
- Terminal Position :
- QUAD
- Terminal Pitch :
- 0.5mm
- Factory Lead Time :
- 8 Weeks
- Base Part Number :
- LTC2654
- Terminal Finish :
- Matte Tin (Sn)
- Operating Temperature :
- -40°C~85°C
- Number of Bits :
- 12
- Number of D/A Converters :
- 4
- Supply Type :
- Single
- JESD-609 Code :
- e3
- Number of Terminations :
- 20
- ECCN Code :
- EAR99
- INL/DNL (LSB) :
- ±0.5, ±0.1
- Supply Current-Max :
- 2.5mA
- Lifecycle Status :
- Production (Last Updated: 4 weeks ago)
- Pin Count :
- 20
- Differential Output :
- No
- Supply Voltage :
- 5V
- Height Seated (Max) :
- 0.8mm
- Voltage - Supply, Analog :
- 5V
- Package / Case :
- 20-WFQFN Exposed Pad
- Datasheets
- LTC2654IUF-H12#PBF
Digital to Analog Converters (DAC) Linear Technology LTC2654IUF-H12#PBF Overview
The LTC2654IUF-H12#PBF from Linear Technology is a cutting-edge Digital to Analog Converter (DAC) that combines high-fidelity, precision, and ease of use in one compact package. Designed to cater to sophisticated electronics that require reliable digital-to-analog conversion, this quad-channel DAC features a 12-bit resolution, providing the accuracy needed for critical applications. Its SPI interface ensures easy integration with microcontrollers and digital systems, making it an ideal choice for designers looking to enhance system performance with minimal effort. The use of advanced silicon technology in the LTC2654IUF-H12#PBF ensures that it delivers consistent performance, making it a pivotal component in the development of high-performance electronics.
LTC2654IUF-H12#PBF Features
This DAC offers several distinctive features that set it apart in the market. It operates over a wide supply range, making it versatile for various power environments. The 12-bit resolution guarantees precise output signals, crucial for achieving accurate analog outputs in sensitive applications. Its quad-channel operation allows for multiple outputs to be controlled simultaneously, enhancing the functionality and efficiency of the overall system. Additionally, the integrated SPI interface facilitates easy communication with most microcontrollers, streamlining development and integration processes.
LTC2654IUF-H12#PBF Applications
- Precision Instrumentation: In lab equipment and scientific instruments, the LTC2654IUF-H12#PBF provides the accuracy and stability required for precise measurements and data acquisition.
- Industrial Control Systems: The DAC is used to convert digital set points into precise analog voltages for controlling actuators and sensors, improving system responsiveness and accuracy in industrial settings.
- Automotive Electronics: Suitable for automotive applications where precise analog control is needed, such as in audio systems or electronic control units.
- Communication Systems: In communication infrastructure, this DAC ensures reliable conversion of digital data into analog signals for processing and transmission.
