MIC5330-MFYML

Manufacturer :

Micrel Inc.

Product Category :

Current Regulation/Management

Supplier Device Package :

8-MLF® (2x2)

Operating Temperature TJ-Min :

-40 °C

Output Current :

0.3 A

Mounting :

Surface Mount

Supplier Package :

VDFN

Output Voltage1-Max :

2.884 V

Output Voltage :

1.5V

Voltage Dropout (Max) :

0.2V @ 300mA 0.2V @ 300mA

Terminal Finish :

Nickel/Palladium/Gold (Ni/Pd/Au)

Pin Count :

8

Output Type :

FIXED

Current - Output :

300mA, 300mA

Operating Temperature :

-40°C~125°C

Base Product Number :

MIC5330

Output Voltage2-Max :

1.545 V

Mount :

Surface Mount

Published :

2011

Function :

LDO

Mounting Type :

Surface Mount

Number of Pins :

8

Current - Quiescent (Iq) :

120μA

Number of Outputs :

2

Packaging :

Tape and Reel (TR)

Terminal Form :

NO LEAD

Number of Regulators :

2

PSRR :

70dB ~ 65dB (1kHz ~ 20kHz)

Min Operating Temperature :

-40°C

Product Status :

Active

Output Voltage2-Min :

1.455 V

Terminal Pitch :

0.5 mm

Output Voltage1-Min :

2.716 V

Operating Temperature TJ-Max :

125 °C

Voltage - Input (Max) :

5.5V

Length :

2 mm

JESD-609 Code :

e4

Factory Lead Time :

12 Weeks

Series :

--

Terminal Position :

Dual

HTS Code :

8542.39.00.01

Voltage - Output (Min/Fixed) :

1.5V 2.8V

Number of Terminals :

8

Protection Features :

Over Current, Over Temperature

Product Type :

LDO Voltage Regulators

Output Voltage1-Nom :

2.8 V

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Max Operating Temperature :

125°C

Mounting Style :

SMD/SMT

Package Shape :

Square

Manufacturer :

Microchip

Technology :

CMOS

Number of Functions :

1

Reach Compliance Code :

Compliant

Input Voltage Range :

2.3, 5.5 V

JESD-30 Code :

S-PDSO-N8

Product Category :

LDO Voltage Regulators

Dropout Voltage1-Max :

0.2 V

Peak Reflow Temperature (Cel) :

260

Dropout Voltage2-Max :

0.2 V

Package / Case :

8-VFDFN Exposed Pad, 8-MLF®

Base Part Number :

MIC5330

ECCN Code :

EAR99

Dropout Voltage :

75mV

Output Configuration :

Positive

Line Regulation :

0.3 %/V

Brand :

Microchip Technology

Surface Mount :

yes

RoHS Status :

ROHS3 Compliant

RoHS :

Details

Junction to Ambient :

90 °C/W

Screening Level :

Extended Industrial

Width :

2 mm

Min Current Limit :

350mA

Subcategory :

PMIC - Power Management ICs

Polarity :

Positive

Seated Height-Max :

0.95 mm

Regulator Type :

FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

Voltage - Output (Max) :

--

Load Regulation :

0.5 %

Control Features :

Enable

Maximum Input Voltage :

5.5 V

Current - Supply (Max) :

200μA

Moisture Sensitivity Level (MSL) :

1 (Unlimited)
