PESD12VS1UAF

Manufacturer :

Nexperia

Product Category :

Number of Terminations :

2

Voltage - Clamping (Max) @ Ipp :

19V

Unidirectional Channels :

1

Voltage - Breakdown (Min) :

13.3V

Mounting Type :

Surface Mount

Type :

Zener

Diode Element Material :

SILICON

Capacitance @ Frequency :

160pF @ 1MHz

Configuration :

Single

Polarity :

Unidirectional

Terminal Form :

Gull wing

Current - Peak Pulse (10/1000μs) :

22.5A 8/20μs

Package / Case :

SC-76, SOD-323

Voltage - Reverse Standoff (Typ) :

12V Max

RoHS Status :

ROHS3 Compliant

Surface Mount :

yes

JESD-30 Code :

R-PDSO-G2

Applications :

Automotive

Packaging :

Tape and Reel (TR)

Operating Temperature :

-55°C~150°C TA

Power - Peak Pulse :

600W

Power Line Protection :

No

Number of Elements :

1

Terminal Position :

Dual

Power Dissipation-Max :

0.5W

Pin Count :

2

Series :

Automotive, AEC-Q101

Factory Lead Time :

4 Weeks
