PHB1405220KRST

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Termination :

PC Pins

Size / Dimension :

2.264" L x 1.378" W (57.50mm x 35.00mm)

Height :

50 mm

Mounting Type :

Through Hole

Package / Case :

Radial - 6 Leads

Product :

General Film Capacitors

Ratings :

-

ESR (Equivalent Series Resistance) :

2.8 mOhms

Product Status :

Active

Product Category :

Film Capacitors

Packaging :

Bulk

Operating Temperature :

-40°C ~ 85°C

Features :

-

Series :

PHB

Applications :

High Frequency, Switching

Lead Spacing :

2.067" (52.50mm)

Brand :

Nichicon

Dielectric :

Polypropylene (PP)

Termination Style :

Radial

Maximum Operating Temperature :

+ 85 C

Number of Pins :

6 Pin

Dielectric Material :

Polypropylene (PP), Metallized

RoHS :

Details

Lead Style :

Straight

Voltage Rating - AC :

275V

Voltage Rating - DC :

400V

Package :

Bulk

Width :

35 mm

Capacitance :

22 µF

Subcategory :

Capacitors

ESR :

2.8 mOhms

Height - Seated (Max) :

1.969" (50.00mm)

Length :

57.5 mm

Product Type :

Film Capacitors

Minimum Operating Temperature :

- 40 C

Tolerance :

±10%

Manufacturer :

Nichicon

Lead Diameter :

1.2 mm
