PHB1603330KGL
Or copy the link below:
- Mfr.Part #
- PHB1603330KGL
- Manufacturer
- Nichicon
- Package / Case
- Radial
- Datasheet
- Download
- Description
- FILM CAP BOXED RADIAL
- Stock
- 27,208
- In Stock ：
- 27,208
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Nichicon
- Product Category :
- Film Capacitors
- Length :
- 26.5 mm
- Product Type :
- Film Capacitors
- Width :
- 8.5 mm
- Number of Pins :
- 4 Pin
- Product Category :
- Film Capacitors
- Voltage Rating - DC :
- 600V
- Subcategory :
- Capacitors
- ESR :
- 9.5 mOhms
- Features :
- -
- Minimum Operating Temperature :
- - 40 C
- Ratings :
- -
- Lead Diameter :
- 0.8 mm
- Voltage Rating - AC :
- 350V
- ESR (Equivalent Series Resistance) :
- 9.5 mOhms
- Product :
- General Film Capacitors
- Height :
- 17 mm
- Applications :
- High Frequency, Switching
- Packaging :
- Bulk
- Series :
- PHB
- Operating Temperature :
- -40°C ~ 85°C
- Package :
- Bulk
- RoHS :
- Details
- Brand :
- Nichicon
- Lead Style :
- Straight
- Maximum Operating Temperature :
- + 85 C
- Termination Style :
- Radial
- Tolerance :
- ±10%
- Package / Case :
- Radial
- Lead Spacing :
- 0.886" (22.50mm)
- Dielectric :
- Polypropylene (PP)
- Mounting Type :
- Through Hole
- Manufacturer :
- Nichicon
- Product Status :
- Active
- Dielectric Material :
- Polypropylene (PP), Metallized
- Size / Dimension :
- 1.043" L x 0.335" W (26.50mm x 8.50mm)
- Height - Seated (Max) :
- 0.669" (17.00mm)
- Termination :
- PC Pins
- Capacitance :
- 0.33 µF
- Datasheets
- PHB1603330KGL
PHB 0.33 μF Film Capacitor ±10% Radial PC Pins Polypropylene (PP), Metallized
PHB1603330KGL Overview
It has 9.5 mOhms ESR (Equivalent Series Resistance).Electrical devices with 0.886" (22.50mm) lead spacing are used in this application.A temperature of -40°C ~ 85°C is suitable for operation of the device.
PHB1603330KGL Features
9.5 mOhms equivalent series resistance (ESR)
PHB1603330KGL Applications
There are a lot of Nichicon
PHB1603330KGL applications of film capacitors.
- Industrial and automotive inverters
- Battery management system
- Test and measuring equipment
- RF Modules
- Mobile communications
- Satellite TV
- Global positioning systems
- Filters
- VCO's
- Matching networks
