PHB1704330KJSDA

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Number of Pins :

6 Pin

Length :

41.5 mm

Maximum Operating Temperature :

+ 85 C

Dielectric Material :

Polypropylene (PP), Metallized

Mounting Type :

Through Hole

RoHS :

Details

Operating Temperature :

-40°C ~ 85°C

Product Category :

Film Capacitors

Product :

General Film Capacitors

Package / Case :

Radial - 4 Leads

ESR (Equivalent Series Resistance) :

3.1 mOhms

Series :

PHB

Minimum Operating Temperature :

- 40 C

Lead Spacing :

1.476" (37.50mm)

Dielectric :

Polypropylene (PP)

Ratings :

-

Brand :

Nichicon

Packaging :

Bulk

Manufacturer :

Nichicon

Capacitance :

3.3 µF

Subcategory :

Capacitors

Voltage Rating - DC :

700V

Termination :

PC Pins

Features :

-

Height :

44 mm

Termination Style :

Radial

Product Status :

Active

Product Type :

Film Capacitors

Size / Dimension :

1.673" L x 1.102" W (42.50mm x 28.00mm)

Tolerance :

±10%

Voltage Rating - AC :

400V

ESR :

3.1 mOhms

Width :

24 mm

Height - Seated (Max) :

1.457" (37.00mm)

Lead Style :

Straight

Package :

Bulk

Applications :

High Frequency, Switching

Lead Diameter :

1.2 mm
