PMB1704330KBP

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Operating Temperature :

-40°C ~ 85°C

Subcategory :

Capacitors

Height :

45 mm

Manufacturer :

Nichicon

Dielectric Material :

Polypropylene (PP), Metallized

Termination Style :

Lug

RoHS :

Details

Capacitance :

3.3 µF

Height - Seated (Max) :

1.772" (45.00mm)

Product Status :

Active

Lead Spacing :

1.516" (38.50mm)

ESR :

2.1 MOhms

Maximum Operating Temperature :

+ 85 C

Package :

Bulk

Mounting Type :

Chassis Mount

Minimum Operating Temperature :

- 40 C

Brand :

Nichicon

Length :

42.5 mm

Dielectric :

Polypropylene (PP)

Type :

High Current

Width :

33 mm

ESR (Equivalent Series Resistance) :

2.1 MOhms

Ratings :

-

Series :

PMB

Features :

-

Termination :

Screw Terminals

Packaging :

Bulk

Product :

Snubber Film Capacitors

Number of Pins :

2 Pin

Product Category :

Film Capacitors

Tolerance :

±10%

Product Type :

Film Capacitors

Voltage Rating - AC :

420V

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Voltage Rating - DC :

700V

Package / Case :

Rectangular Box

Size / Dimension :

1.673" L x 1.299" W (42.50mm x 33.00mm)
