PMB1853680KSL

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Voltage Rating - DC :

850V

Termination :

Screw Terminals

Mounting Type :

Chassis Mount

Series :

PMB

Width :

17 mm

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Subcategory :

Capacitors

Capacitance :

0.68 μF

Ratings :

-

Voltage Rating - AC :

500V

Maximum Operating Temperature :

+ 85 C

Product :

Snubber Film Capacitors

Height - Seated (Max) :

1.102" (28.00mm)

Tolerance :

±10%

Dielectric Material :

Polypropylene (PP), Metallized

ESR (Equivalent Series Resistance) :

3.5 mOhms

Manufacturer :

Nichicon

Dielectric :

Polypropylene (PP)

Package / Case :

Rectangular Box

Lead Spacing :

0.906" (23.00mm)

Operating Temperature :

-40°C ~ 85°C

Type :

High Current

Brand :

Nichicon

Packaging :

Bulk

Product Category :

Film Capacitors

Features :

-

Size / Dimension :

1.673" L x 0.669" W (42.50mm x 17.00mm)

Height :

28 mm

Product Status :

Active

Minimum Operating Temperature :

- 40 C

ESR :

3.5 mOhms

Package :

Bulk

Product Type :

Film Capacitors

RoHS :

Details

Termination Style :

Lug

Number of Pins :

2 Pin

Length :

42.5 mm
