PMB2103470KVR

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Maximum Operating Temperature :

+ 85 C

ESR (Equivalent Series Resistance) :

3.9 MOhms

Height - Seated (Max) :

1.102" (28.00mm)

Product :

Snubber Film Capacitors

Features :

-

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Ratings :

-

RoHS :

Details

Voltage Rating - DC :

1000V (1kV)

Capacitance :

0.47 µF

Termination Style :

Lug

Brand :

Nichicon

Number of Pins :

2 Pin

Minimum Operating Temperature :

- 40 C

Product Type :

Film Capacitors

Subcategory :

Capacitors

Width :

17 mm

Length :

42.5 mm

Product Status :

Active

Tolerance :

±10%

Product Category :

Film Capacitors

Dielectric :

Polypropylene (PP)

Packaging :

Bulk

Operating Temperature :

-40°C ~ 85°C

Height :

28 mm

ESR :

3.9 MOhms

Termination :

Screw Terminals

Package :

Bulk

Type :

High Current

Lead Spacing :

-

Dielectric Material :

Polypropylene (PP), Metallized

Manufacturer :

Nichicon

Size / Dimension :

1.673" L x 0.669" W (42.50mm x 17.00mm)

Series :

PMB

Voltage Rating - AC :

575V
