PPA2301680KJ

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Diameter :

8.5 mm

Capacitance :

6800 pF

Minimum Operating Temperature :

- 40 C

ESR (Equivalent Series Resistance) :

77 mOhms

Type :

Cylindrical

Package / Case :

Axial

Product Type :

Film Capacitors

Lead Style :

Straight

Features :

-

Voltage Rating - DC :

3000V (3kV)

Ratings :

-

Dielectric Material :

Polypropylene (PP), Metallized

Dielectric :

Polypropylene (PP)

Termination :

PC Pins

Operating Temperature :

-40°C ~ 85°C

Number of Pins :

2 Pin

Product Status :

Active

Tolerance :

±10%

Length :

32 mm

Termination Style :

Axial

Height - Seated (Max) :

-

Product :

Snubber Film Capacitors

Manufacturer :

Nichicon

ESR :

77 mOhms

Mounting Type :

Through Hole

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Package :

Bulk

Maximum Operating Temperature :

+ 85 C

RoHS :

Details

Subcategory :

Capacitors

Lead Spacing :

-

Size / Dimension :

0.413" Dia x 1.063" L (10.50mm x 27.00mm)

Series :

PPA

Voltage Rating - AC :

750V

Packaging :

Bulk

Product Category :

Film Capacitors

Brand :

Nichicon

Lead Diameter :

0.8 mm
