PSB1703680KHS

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Termination :

PC Pins

Lead Style :

Straight

Product Category :

Film Capacitors

Package :

Bulk

Package / Case :

Radial

Voltage Rating - DC :

700V

Operating Temperature :

-40°C ~ 85°C

Product Type :

Film Capacitors

Features :

-

Minimum Operating Temperature :

- 40 C

Size / Dimension :

1.260" L x 0.709" W (32.00mm x 18.00mm)

Lead Diameter :

1.2 mm

Lead Spacing :

1.083" (27.50mm)

RoHS :

Details

Manufacturer :

Nichicon

Width :

18 mm

Length :

32 mm

ESR :

3.8 mOhms

Mounting Type :

Through Hole

Height - Seated (Max) :

1.299" (33.00mm)

Termination Style :

Radial

Packaging :

Bulk

Product :

General Film Capacitors

Ratings :

-

Series :

PSB

Dielectric Material :

Polypropylene (PP), Metallized

Product Status :

Active

Height :

33 mm

Dielectric :

Polypropylene (PP)

Brand :

Nichicon

Number of Pins :

4 Pin

Voltage Rating - AC :

420V

Subcategory :

Capacitors

Capacitance :

0.68 μF

ESR (Equivalent Series Resistance) :

3.8 mOhms

Maximum Operating Temperature :

+ 85 C

Tolerance :

±10%
